Suzuki SWIFT 2005 User Manual

Body Electrical Control System: 10B-32
BCM connector “E46”
L01-8
“3” position switch
(A/T model)
*0 – 1 V
↑↓
10 – 14 V
Refer to “Reference waveform No. 2: ”
0 V
Ignition switch is at ON position and A/T select lever is at
“2” or “3” position
L01-9 — — —
L01-10
Driver side door lock actuator
control (Unlock) (if equipped)
10 – 14 V Unlock signal is output for driver side door lock actuator.
0 V
Unlock signal is not output for driver side door lock
actuator.
L01-11
Rear end door opener
actuator control
0 V Rear end door opener actuator is not in operation
10 – 14 V Rear end door opener actuator is in operation
L01-12
Manual door lock switch
(Lock)
10 – 14 V
Manual door lock switch is at any position other than lock
position
0 V Manual door lock switch is at lock position
L01-13 — — —
L01-14 Driver side seat belt switch
*0 – 3 V
↑↓
10 – 14 V
Refer to “Reference waveform No. 3: ”
0 V
Ignition switch is at ON position and driver side seat belt
is unfastened
L01-15
Door switch (other than driver
side door and rear end door)
10 – 14 V
Rear right and left side door and passenger side door are
closed
0 V
Any one of the door is opened (except driver side door
and rear end door)
L01-16 Driver side door key cylinder
switch (Lock)
10 – 14 V
Driver side door key cylinder switch is at any position
other than lock position
0 V Driver side door key cylinder switch is at lock position
L01-17
Driver side door key cylinder
switch (Unlock)
10 – 14 V
Driver side door key cylinder switch is at any position
other than unlock position
0 V Driver side door key cylinder switch is at unlock position
L01-18 — — —
Terminal Circuit Normal voltage Condition
Terminal Circuit Normal voltage Condition
E46-1
CAN communication line
(high) for ABS/ESP® control
module
*2.5 – 3.6 V
Refer to “Reference waveform No. 4: ”
E46-2
CAN communication line
(low) for ABS/ESP® control
module
*1.6 – 2.5 V
E46-3 — — —
E46-4 Generator “L” terminal
10 – 14 V Engine is running
0 V Ignition switch is at ON position
E46-5 Brake fluid level switch
*0 – 3 V
↑↓
10 – 14 V
Refer to “Reference waveform No. 1: ”
0 V
Ignition switch is at ON position, parking brake lever is
released and brake fluid level is lower than MIN level
E46-6 — — —
E46-7 — — —
E46-8
Sensor ground for outside air
temperature sensor
(if equipped)
0 V —
E46-9
Serial communication line of
data link connector for ECM,
TCM, ABS and P/S control
module
8 – 12 V Ignition switch is at ON position
E46-10
Outside air temperature
sensor (if equipped)
About 1.5 V
Ignition switch is at ON position and outside air
temperature approx. 20 °C (68 °F)
