1D-65 Engine Mechanical:
NOTE
The specified tightening torque is also described in the following.
“Air Cleaner Components”
“Throttle Body and Intake Manifold Components”
“Engine Mountings Components”
“Timing Chain Cover Components”
“Timing Chain and Chain Tensioner Components”
“Camshaft, Tappet and Shim Components”
“Valves and Cylinder Head Components”
“Pistons, Piston Rings, Connecting Rods and Cylinders Components”
“Main Bearings, Crankshaft and Cylinder Block Components”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Fasteners Information in Section 0A”.
Connecting rod bearing cap bolt 15 N⋅m (1.5 kgf-m, 11.0 lb-ft) and then
retighten by turning through 45° twice
) / )
Sensor plate bolt 11 1.1 8.0 )
Piston cooling valve 11 1.1 8.0 )
Main bearing cap No.1 bolt (a) 30 N⋅m (3.0 kgf-m, 22.0 lb-ft), 50 N⋅m (5.0
kgf-m, 36.5 lb-ft) and then retighten by
turning through 60°
)
Main bearing cap No.2 bolt (b) 25 2.5 18.0 )
Rear oil seal housing bolt 11 1.1 8.0 )
Flywheel or drive plate bolt 70 7.0 51.0 )
Main bearing cap No.1 bolt 30 N⋅m (3.0 kgf-m, 22.0 lb-ft), 50 N⋅m (5.0
kgf-m, 36.5 lb-ft) and then retighten by
turning through 60°
)
Main bearing cap No.2 bolt 25 2.5 18.0 ) / )
Main bearing cap No.1 bolt 30 Nm (3.0 kgf-m, 22.0 lb-ft), 50 Nm (5.0
kgf-m, 36.5 lb-ft) and then retighten by
turning through 60°
)
Fastening part
Tightening torque
Note
N⋅mkgf-mlb-ft
