Front Suspension: 2B-20
Specifications
Tightening Torque Specifications
S7RS0B2207001
NOTE
The specified tightening torque is also described in the following.
“Front Suspension Construction”
“Front Strut Assembly Components”
“Front Wheel Hub and Steering Knuckle Components”
“Front Suspension Frame, Stabilizer Bar and/or Bushings Components”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Fasteners Information in Section 0A”.
Fastening part
Tightening torque
Note
N⋅mkgf-mlb-ft
Tie-rod end lock nut 45 4.5 32.5 )
Strut bracket nut 90 9.0 65.5 ) / )
Brake hose mounting bolt 25 2.5 18.0 )
Stabilizer joint nut 50 5.0 36.5 ) / )
Strut nut 50 5.0 36.5 )
Wheel nut 85 8.5 61.5 ) / ) / )
Strut support lower nut 50 5.0 36.5 )
Suspension control arm ball joint nut 60 6.0 43.5 ) / )
Wheel speed sensor mounting bolt 11 1.1 8.0 )
Caliper carrier bolt 85 8.5 61.5 )
Drive shaft nut 200 20.0 145.0 )
Suspension control arm front bolt 95 9.5 68.0 )
Suspension control arm rear bolt 95 9.5 68.0 )
Stabilizer bar mounting bracket bolt 23 2.3 17.0 )
Steering gear case mounting No.1 bolt 55 5.5 40.0 )
Steering gear case mounting No.2 bolt 55 5.5 40.0 )
Front suspension frame mounting bolt 150 15.0 108.5 )
Engine rear mounting bolt 55 5.5 40.0 )
Steering shaft joint bolt 25 2.5 18.5 )
Wheel bolt 85 8.5 61.5 )
