ABS: 4E-6

1. Battery 12. Pump motor 23. Internal memory

2. Main fuse box 13. Solenoid valves 24. Solenoid valve driver (transistor)

3. Ignition switch 14. Right-rear wheel speed sensor 25. ECM

4. Circuit fuse box 15. Left-rear wheel speed sensor 26. BCM

5. Combination meter 16. Right-front wheel speed sensor 27. Brake fluid level switch

6. ABS warning light 17. Left-front wheel speed sensor 28. Parking brake switch

7. EBD warning light (Brake warning light) 18. Data link connector 29. CAN driver

8. Lamp driver module 19. To ECM, SDM and BCM

9. ABS hydraulic unit / control module assembly 20. Stop lamp

Terminal Wire color Circuit

E03

1 WHT/RED ABS pump motor driver (Transistor)

2— —

3— —

4— —

5 PPL/WHT Data link connector

6 WHT CAN communication line (low) for BCM

7 GRN/ORN Ignition switch

8 WHT CAN communication line (low) for ECM

9— —

10 RED CAN communication line (high) for ECM

11 — —

12 RED CAN communication line (high) for BCM

13 BLK Ground

14 WHT/BLU Solenoid valve power supply driver (Transistor)

15 LT GRN/BLK Left–rear wheel speed sensor (–)

16 LT GRN Left–rear wheel speed sensor (+)

17 — —

18 WHT Right–front wheel speed sensor (+)

19 WHT/BLK Right–front wheel speed sensor (–)

20 — —

21 RED/BLK Left–front wheel speed sensor (–)

22 RED Left–front wheel speed sensor (+)

23 — —

24 YEL Right–rear wheel speed sensor (+)

25 BRN Right–rear wheel speed sensor (–)

26 BLK Ground
