Automatic Transmission/Transaxle: 5A-167
Specifications
Tightening Torque Specifications
S7RS0B5107001
NOTE
The specified tightening torque is also described in the following.
“Select Cable Components”
“Automatic Transaxle Unit Components”
“Automatic Transaxle Assembly Components”
“Oil Pump Assembly Components”
“Transaxle Rear Cover (O/D and 2nd Coast Brake Piston) Assembly Components”
“Valve Body Assembly Components”
“Differential Assembly Components”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Fasteners Information in Section 0A”.
Fastening part
Tightening torque
Note
N⋅mkgf-mlb-ft
A/T fluid drain plug 17 1.7 12.5 ) / ) / )
Transmission range sensor bolt 5.5 0.55 4.0 ) / )
Output shaft speed sensor bolt 13 1.3 9.5 ) / )
Input shaft speed sensor bolt 5.5 0.55 4.0 )
Valve body harness connector bolt 7.0 0.7 5.0 )
Shift solenoid bolt 11 1.1 8.0 )
Oil strainer bolt 10 1.0 7.5 ) / )
Oil pan bolt 7.0 0.7 5.0 ) / )
Transaxle and engine fastening bolt and nut 85 8.5 61.5 )
Drive plate to torque converter bolt 25 2.5 18.0 )
Transaxle stiffener bolt 55 5.5 40 )
Starter motor bolt and nut 50 5.0 36.5 )
Oil pump subassembly bolt 10 1.0 7.5 )
Rear cover plug 7.5 0.75 5.5 )
Solenoid valve bolt 11 1.1 8.0 )
Final gear bolt 78 7.8 56.5 )
Torque converter housing plug 7.5 0.75 5.5 )
Lubrication tube clamp bolt 5.5 0.55 4.0 )
Fluid reservoir RH plate bolt 5.5 0.55 4.0 )
Torque converter housing bolt 29 2.9 21 ) / ) / )
Manual detent spring bolt 10 1.0 7.5 )
Parking lock pawl bracket bolt 7.5 0.75 5.5 )
Rear cover bolt 25 2.5 18.0 )
Fluid reservoir LH plate bolt 10 1.0 7.5 )
Oil pump assembly bolt 25 2.5 18.0 )
Transaxle case plug 7.5 0.75 5.5 )
Valve body harness connector bolt 5.5 0.55 4.0 )
Valve body bolt 11 1.1 8.0 )
Fluid outlet union 25 2.5 18.0 )
Fluid cooler pipe union bolt 22 2.2 16.0 )
Fluid cooler pipe bracket bolt 10 1.0 7.5 )
Fluid filler tube bolt 10 1.0 7.5 )
Input shaft speed sensor bolt 11 1.1 8.0 )
Harness bracket bolt 23 2.3 17.0 )
Select cable clamp bolt 10 1.0 7.5 )
Transmission range sensor lock nut 7 0.7 5.0 )
Manual select lever nut 13 1.3 9.5 )
Engine mounting LH bracket bolt 55 5.5 40.0
)
