6C-10 Power Assisted Steering System:
) C1121
No vehicle speed signal
(60 seconds or more)
Vehicle speed signal is 0 km/h
even though engine speed is
more than 4000 rpm for more than
60 seconds continuously (before
elapse of 5 min from engine start)
or vehicle speed signal is 0 km/h
even though engine speed is
more than 2500 rpm for more than
60 seconds continuously (after
elapse of 5 min for engine start).
• Vehicle speed signal circuit
• Wheel speed sensor
•ECM
• P/S control module
• ABS control module
• CAN communication circuit
Not
applicable
) C1122 Engine speed signal
Engine speed signal is less than
220 rpm for more than 0.8
seconds.
or
Engine speed signal is less than
220 rpm for more than 20
seconds continuously even
though vehicle speed signal is
more than 50 km/h.
• Engine speed signal circuit
•ECM
• P/S control module
• Vehicle speed signal
1 driving
cycle
) C1123
No vehicle speed signal
(30 seconds or more)
Vehicle speed signal is 0 km/h
with continuously more than 3
driving cycles even though engine
speed is more than 4000 rpm for
more than 30 seconds
continuously (before elapse of 5
min from engine start).
or
vehicle speed signal is 0 km/h
with continuously more than 3
driving cycles even though engine
speed is more than 2500 rpm for
more than 30 seconds
continuously (after elapse of 5 min
for engine start).
• Vehicle speed signal circuit
• Wheel speed sensor
•ECM
• P/S control module
• ABS control module
• CAN communication circuit
3 driving
cycles
) C1124
Vehicle speed performance
(Impossible deceleration)
Vehicle speed signal is less than 5
km/h for more than 5 seconds
continuously with more than
specified deceleration speed (–20
m/s
2
) from over 20 km/h.
Not
applicable
) C1141 P/S motor circuit voltage
Voltage between both motor drive
circuits is more than 8.5 V or less
than 0.2 V for 0.5 seconds
continuously while motor is not
drived.
• P/S motor circuit
• P/S motor
• P/S control module
1 driving
cycle
) C1142
P/S motor circuit range /
performance
Measured motor drive current is
more than 10 A as compared with
target motor drive current.
1 driving
cycle
DTC No. Detecting item
Detecting condition
(DTC will set when detecting)
Trouble area MIL
