SVAN 948 USER MANUAL .
2 - 2
Notice: The operation of this push button can be set as the “Shift” mode or the “2nd Fun.”
mode in the SHIFT MODE window of the SETUP list (see Chapter 5 for the SETUP list description).
<START / STOP>
This push-button enables one to start the measurement process, when the instrument is not
measuring or to stop it, when the instrument is measuring. It is also possible to set such mode of this
push-button, in which in order to start or stop the measurements the user has to press it simultaneously
with the <SHIFT> one.
Notice: The changing of the <START / STOP> push-button mode is performed in the
SHIFT MODE window of the SETUP list (see Chapter 5 for the SETUP list description).
<PAUSE>
This push-button enables one to break temporary the measurement process. The last one second
measurement result is deleted after the subsequent pressing of the <PAUSE> push-button. Up to fifteen
last seconds of the measurement can be cancelled in this way.
(<PROCEED>)
This push-button (pressed together with the <SHIFT> one) enables the user to continue the
measurement process stopped temporary by pressing the <PAUSE> push-button.
Notice:
The simultaneous pressing of the <PAUSE>
and <START / STOP>
push-buttons switches the instrument on and off.
<ENTER>
This push-button enables one to enter the selected operation mode or to confirm control options.
Some additional functions of this push-button will be described in the following chapters.
(<MENU>)
This push-button (pressed together with the <SHIFT> one) enables the user to enter the main list
containing six sub-lists: FUNCTION, INPUT, DISPLAY, FILE, AUX. FUNCTIONS and SETUP. Each
of the mentioned above sub-lists consists of the sub-lists, elements and data windows. These main sub-
lists will be detailed described in the following chapters of the manual. Double pressed <MENU> push-
button enters the list containing four last opened sub-lists. It often speeds up the control of the instrument.
<ESC>
This push-button closes the control lists, sub-lists or windows. It acts in opposite to the <ENTER>
push-button. When the window is closed pressing the <ESC> push-button, any changes made in it are (in
almost all cases) ignored.
(<›
››
› >)
This push-button (pressed together with the <SHIFT> one) enables the user to switch on or off the
backlight of the screen and the keyboard.
