APPENDIX C  UNIT SPECIFICATIONS
Dimensions Matrix Pro 570GS 16.15 x 14.91 x 5.84 cm
Matrix Pro 840GS 27.0 x 18.0 x 6.0 cm
Weight Matrix Pro 570GS 0.794 kg
Matrix Pro 840GS 1.06 kg
Connector Power/CAN 8 pin Conxall
Camera 5 pin Conxall
Speed/Status
8 pin Conxall
WARNING! Some original Matrix consoles have a 4 pin conxall cable connection. The 4-pin and 8-pin cables are NOT
interchangable.
Environmental Storage -10 to +70°C
Operating 0 to +50°C
Humidity 90% non-condensing
Display Matrix Pro 570GS 320 x 240 resolution, 14.5 cm
Matrix Pro 840GS 800 x 600 resolution , 21.3 cm
Input/output
USB 2.0
Power requirement < 9 watts @ 12 VDC
