TeeJet Matrix Pro 570GS - Cultural; Audio Volume

32
www.teejet.com
MATRIX
®
Pro 570GS
•
MATRIX
®
Pro 840GS
HOME GUIDANCEFULL SCREEN IMPLEMENTINTRODUCTION GNSS RATE CONTROL APPENDIXSETUP
Cultural
Cultural is used to congure units, language, and time zone
settings.
1. Press CONSOLE side tab .
2. Press
Cultural .
3. Select from:
►Units – used to dene the system units
►Language – used to dene the system language
►Time zone – used to establish the local time zone
4. Press RETURN arrow or CONSOLE side tab to
return to the main Console Settings screen.
Figure 4-44: Cultural options
Audio volume
Audio volume adjusts the volume level of the audio speaker.
1. Press CONSOLE side tab .
2. Press Audio Volume .
3. Press:
►UP arrow to increase the sound
►DOWN arrow to soften the sound
4. Press RETURN arrow or CONSOLE side tab to
return to the main Console Settings screen.
Figure 4-45: Audio volume options
