5.3 Reference Guide using RS-232C commands
103
devices(that have not previously exchanged link keys) to each other and create a trusted relationship
between then and is used in pairing procedure to generate the initial link key that is used for further
authentication.
Value
PIN code : 16 bytes as a hexadeciamal notation
(ex) In case of “1234”, input “31.32.33.34.30.30.30.30.30.30.30.30.30.30.30.30”
READ:SYS:TESTER:SKIP_PAIR?
Description
This command reads the flag to skip pairing procedure.
CONF:SYS:TESTER:SKIP_PAIR <Value>
Description
This command writes the flag to skip pairing procedure. If the flag to skip pairing is ON, the link key, which is
defined by “CONF:SYS:TESTER:LINK_KEY” will be used for authentication procedure.
Value
the flag to skip pairing procedure : ON, OFF(default)
READ:SYS:TESTER:LINK_KEY?
Description
This command reads the link key which is used for authentication procedure if the flag to skip pairing is ON.
CONF:SYS:TESTER:LINK_KEY <Value>
Description
This command writes the link key which is used for authentication procedure if the flag to skip pairing is ON.
Value
Link key : 16 bytes as a hexadeciamal notation
For example, input “C3.82.92.B4.C5.F2.39.79.24.4A.F0.96.55.1A.E8.98”.
READ:SYS:TESTER:BD_ADDR?
Description
This command reads Bluetooth Device ADDRess(BD_ADDR) of a tester.
CONF:SYS:TESTER:BD_ADDR <Value>
Description
This command writes Bluetooth Device ADDRess(BD_ADDR) of a tester.
Value
Bluetooth device address : 9abc56781234(default)
READ:SYS:TESTER:MOD_INDEX?
Description
This command reads FSK modulation index.
CONF:SYS:TESTER:MOD_INDEX <Value>
Description
This command writes FSK modulation index.
Value
modulation index : 0.28 ~ 0.35, 0.32(default)
READ:SYS:TESTER:ENCRYPTION?
Discription
This command reads Encryption parameter of LMP features.
