Manual 0-5401 APPENDIX A A-1
APPENDIX A
A.1 Bios settings
Connect a keyboard to one of the USB ports on the CNC
Use arrow keys to move, enter to go into menus and select, Esc to go back in menus and +/- to move items.
Turn on iCNC Performance and Press Del button on the keyboard to enter BIOS.
BIOS
Press F9 to load Setup Defaults
--> Main
--> Set System Date and Time
--> Advanced
--> Serial ATA (SATA)
--> SATA Controller Mode [ACHI]
--> North Bridge Configuration
--> IGD Configuration
--> IDG-LCD PANEL TYPE [1024x768 LVDS Color Panel]
--> Boot
Move USB HDD, USB CD, USB FDD and ATAPI CD all the way to the bottom:
1. ATA HDD0: Intel …
2. ATA HDD1:
3. Other HDD
4. Internal Shell
5. PCI LAN
6. PCIe HDD
7. USB HDD
8. USB CD
9. USB FDD
10.ATAPI CD
-->Exit Saving Changes
