B-12 APPENDIX B Manual 0-5401
B.2.6 75VDC Power Suply Dimensions
205.5
[8.09]
191
[7.53]
95 [3.75]
175
[6.9]
1.3
[0.05]
23 [0.91]
6.6
[0.26]
6.35
[0.25]
98.3 [3.87]
Inlet connector
DC output
Voltage selection switch
AC Input Connector / Pinout
1
10
5
6
wire entry view
1
2
3
4
10
5
7
8
9
6
Pos. 115 VAC 230 VAC
NC
NC
AC IN
NC
NC = No Connect
AC IN
GND
NC
NC
Jump to 9
Jump to 7
NC
NC
Jump to 9
NC
Jump to 7
GND
AC IN
AC IN
Jump to 10
Jump to 6
DC Output Connector / Pinout
1 2
wire entry view
Pos. Signal
DC Bus (V+)
DC Bus (V-)
1
2
!
CAUTION
Power supply wired for 115VAC as default!
