iCNC Perfromance
Manual 0-5401 APPENDIX B B-17
B.4.4 Lifter Cable
Limit gnd
Limit up
Limit 24Vdc
Motor B-
Motor B+
Motor A-
Shield
Torch Collition
Motor A+
1
2
3
4
5
6
MOTOR
Molex 51067-0600
Pins: Molex 50217-9101
A+ (green)
A- (yellow)
B- (white)
B+ (brown)
Shield
1
Label: Sensors
Label: Motor
1
14
2
15
3
16
4
17
5
18
6
19
7
20
8
21
9
22
10
23
11
24
12
25
13
J54 LIFTER
Connector: Wurth 61802524823 (male subD25)
Plastic Hood: Wurth 61802525322
Limit 24Vdc (white)
Limit out (green)
Limit GND (brown)
Torch Breakaway 1 Output (yellow)
1
2
3
4
5
6
7
8
9
SENSORS
Connector: AMP 182645-1 (9 pin female receptacle)
Pins: AMP 1-66105-9 female (tin)
Cable Clamp: AMP 182663-1 (size 13 clamp)
Torch Breakaway 1 24Vdc
Torch Breakaway 2 24Vdc
Torch Breakaway 2 Gnd
Pointer 24Vdc (grey)
Pointer GND
Pointer 24V
Description Cat Part#
J54 iHC XT Lifter Motor Cable - 10 ft 15-5018
J54 iHC XT Lifter Motor Cable - 25 ft
J54 iHC XT Lifter Motor Cable - 50 ft
J54 iHC XT Lifter Motor Cable - 75 ft
15-5019
15-5020
15-5021
J54 iHC XT Lifter Motor Cable - 100 ft 15-5022
Shield
Shield
Cable: Shielded 2x2x0.5mm²
Cable: Shielded 3x2x0.5mm²
