iCNC Performance
B-20 APPENDIX B Manual 0-5401
B.4.7 A-series Plasma Adapter Cable
Cable: Shielded 5 x 2 x 0.25mm²
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
J56 - PLASMA ADAPTER
Connector: AMP 206838-2 (24pin Male Receptacle)
Pins: AMP 1-66103-8 (pin tin)
Cable Clamp: AMP 1-206138-0 (size 23)
Plasma Start COM
Plasma Start NO
Input GND
Main Arc In
Arc Voltage-
Arc Voltage+
Sense Relay GND
Sense Relay 24V
Contact GND
Plate Contact In
IO Shield
Label: J1 - CUTMASTER
1
2
3
4
5
6
7
8
9
10
11
12
13
14
J1
Connector: AMP 182649-1 (14pin Male Plug)
Pins: AMP 1-66103-8 (pin tin)
Cable Clamp: AMP 1-206070-0 (size 17)
Plate Contact Out
Contact GND
Arc Voltage+
Arc Voltage-
Sense GND
Sense 24V
Plasma Start NO
Plasma Start COM
Main Arc NO
Main Arc COM
Ohmic
Wire Colors on J56:
1 - white
2 - brown
7 - green
8 - yellow
10 - grey
11 - pink
12 - blue
13 - red
14 - black
15 - violet
Label: OHMIC IN
Shield
To Next Page
