iCNC Perfromance
Manual 0-5401 SPECIFICATIONS 2-1
SECTION 2: SPECIFICATIONS
2.1 System Description
iCNC Performance is intended for shape cutting control. iCNC Performance has motion control, I/O, user interface and an
optional plasma height control built all in one package. These units are not field repairable. Unauthorized opening of the unit
will void the warranty.
2.2 Specification
Processor 2, Intel (secondary processor for motion & I/O)
Operating system Windows 7 Embedded
Ram 2GB
Ethernet ports 1 RJ-45 and 1 WLAN
USB ports 2, 1 On back wall (USB2.0) + 1 On door (USB2.0)
Serial ports 1 RS-422/485 port on d-sub 9 pin
Hard drive 120GB SATA SSD
Operating console Total of 35 buttons and a digital potentiometer
Display 15” With touch panel (resistive)
Number of I/O 20 outputs and 16 inputs
I/O type Outputs and inputs are grounding
Axis available 1-2 Y, 1 X, optional 1Z (iHC)
Default drives interface Analog +-10V speed signal, step/direction (2 axis command), incremental encoder inputs
Integrated plasma height con-
trol
Optional iHC height control
CNC input power volts (amps) 24VDC (5A), with optional iHC 24VDC 6A.
CNC protection device Automatic fuse
Operating temperature -10 C° - +50 C° / 14°F - 122°F
!
WARNING
Do not operate or service the device without proper training.
WARNING
Device is not meant to be serviced in the eld. Contact your dealer for repair.
!
WARNING
DO NOT CONNECT the controller directly to a computer through the RJ45 or RS232 port! Connections must be made with
ber optic devices, wireless LAN, short haul modems or other approved devices which provide galvanic isolation, due to
ground loops, electrical noise, or high frequency which can destroy electrical components in the controller or host com-
puter. Failure to follow these rules will VOID THE WARRANTY!
This device is provided with an integrated PLC and a Windows based user interface.
1. Use minimum 75 ºC copper wire only
2. Use Copper Conductors Only
3. Suitable for use on a circuit capable of delivering not more than 5000 RMS symmetrical amperes, 230 VAC maximum.
