iCNC Perfromance
Manual 0-5401 APPENDIX B B-1
APPENDIX B
B.1 Servo Adapter Card (optional)
INPUTSSERVOENCODEROUTPUTS
Output section
Encoder section
Servo section
Inputs section
Teknic section
External stop section
The servo adapter card provides screw on terminals with connectors for all iCNC performance signals.
B1.1 Dimensions
271
130
( 262 )
( 120 )
( 60 )
( 138 )
[10.67]
[5.12]
( [4.72] )
( [5.43] )
( [2.36] )
( [10.32] )
Holes M3
