Thermal Dynamics iCNC Performance User Manual

iCNC Perfromance
Manual 0-5401 APPENDIX B B-7
B.1.8 Servo Adapter Card Connection Example
INPUTSSERVOENCODEROUTPUTS
1 2
Over travel X+
Inputs 1
GND In00 GND In01 GND In02 GND In03
1 2
Over travel X-
1 2
Over travel Y+
1 2
Over travel Y-
Outputs1
Low PreHeat Solenoid
Cut Oxygen Solenoid
COM COM COM COM COM
Out04 Out00 Out01 Out02 Out03
DC Lifter
GND DC-
A-COM
VCC DC+ A-NO
DC
Supply
for
DC motor
AC
Supply
for
AC motor
AC/DC
Supply
for
solenoids
E-Stop
Sub-D 15
Female
J48
Sub-D 15
Male
Sub-D 15
Male
J47
Sub-D 15
Female
Sub-D 25
Female
J46
Sub-D 25
Male
Sub-D 25
Male
J45
Sub-D 25
Female
To iCNC Performance
15-6012
15-6014 15-6015
15-6013
Power
Connector
E1/E2
