7.11.10.2 BAL Absolute Value Setup
In the formula used to judge the balance of the two windings, to set whether the final result is
compared with the absolute value.
For example, the formula Lx1-Lx2:
When the absolute value switch is ON, the formula will be converted to |Lx1-Lx2|, and the result
will be the absolute value of Lx1-Lx2 compared with the set upper and lower limits;
When the absolute value switch is OFF, the formula will be converted to Lx1-Lx2, the result will be
directly compared with the upper and lower limits set, and the result can be positive or negative.
7.11.10.3 BAL Formula Setup
Currently, there are 5 formulas to choose from, which are as follows:
Lx1-Lx2, DCR1-DCR2, DCR1-DCR2, DCR1-DCR2, DCR1-DCR2
When the absolute value switch is changed, it will affect the final result of this formula.
