Tonghui TH2840 Series - Performance and Test; Test Function; Parameter and Symbol

117
Chapter 8 Performance and Test
8.1 Test function
8.1.1 Parameter and symbol
8.1.1.1 LCR Module
8.1.1.2 Transformer single group module
Parameter
name
Parameter
meaning
Parameter
name
Parameter
meaning
Cp
Equivalent parallel
capacitance
Cs
Equivalent series
capacitance
Lp
Equivalent parallel
inductance
Ls
Equivalent series
inductance
Rp
Equivalent parallel
resistance
Rs
Equivalent series
resistance
Gp
Conductance
Bp
Susceptance
Z
Absolute value of
impedance
Y
Absolute value of
admittance
D
Loss factor
Q
Quality factor
θz°
Impedance degree
θz
Impedance radian
θy°
Admittance degree
θy
Admittance radian
X
Reactance
Rd
DC Resistance
Parameter
name
Parameter
meaning
Parameter
name
Parameter
meaning
Cp
Equivalent parallel
capacitance
Cs
Equivalent series
capacitance
Lp
Equivalent parallel
inductance
Ls
Equivalent series
inductance
Rp
Equivalent parallel
resistance
Rs
Equivalent series
resistance
D
Loss factor
Q
Quality factor
Zx
Absolute value of
impedance
Rd
DC Resistance
Lk
Leakage inductance
dZ
Impedance angle
