4.1.3.2 Address
Parameter type: input type
Parameter function: used to control and display the RS485, GPIB interface and Modbus bus address
of the current instrument.
Value range: 1~32
4.1.3.3 Cmd mode
Parameter type: enumerated
Parameter function: command mode can be set with SCPI command and ModeBus command
protocol.
Adopt general ascii string command protocol
Adopt ModBus command protocol
For related introduction, please refer to Chapter 11 Communication Command Reference Chapter.
4.1.4 LAN
Configure the corresponding address parameters according to the specific attributes of the connected
LAN, and plug in the network cable on the rear panel to use the network port for communication.
If you need to modify the relevant address parameters, you can directly double-click the
corresponding address display window to pop up the numeric keyboard, enter the correct network
configuration on the numeric keyboard, and click OK to exit the keyboard to complete the
modification;
If the connected networking equipment (router or switch) supports the automatic IP allocation
function, you can directly click the automatic configuration button in the display window to try the
automatic configuration. The configuration takes a few seconds. Do not operate the machine during
the configuration process; if it does not support it You need to manually assign the setting address; if
the automatic configuration fails, you may get the loopback IP address of the machine, that is,
127.0.0.1; at this time, you can click the default setting button in the display window to restore the
default configuration, and then start again on the basis of the default configuration. Just make fine
adjustments, and you can consult the company's network technical engineer to obtain the address
parameters of the network configuration.
Default port number: 45454
The host name generally corresponds to the instrument model.
