automatic test system through the HANDLER interface to realize the automatic sorting test.
These limit settings can only be set on the <Limit Setup> page.
Optional setting of comparison function: on or off (ON or OFF), the default state is: OFF.
3.1.4.2 Bin count function
It is used to record and display the count value of each bin.
Optional setting of counting function: on or off (ON or OFF), the default state is: OFF.
3.1.4.3 Count reset
Perform a clearing operation on the count result of the current bin, so that the bin count is reset to 0,
which is used to restart counting.
3.1.5 Save the bridge test results on the USB flash drive
Use the USB flash drive to save the test results.
The test results and formats that can be saved are as follows:
Time,P1,P2,P3,P4,BIN
----Respectively correspond to the test time, parameter 1~4 result, bin result
Save the switch;
The naming rule of the file name is rx+machine number+date,
such as: rx-SN12345678-20210811.csv,
3.2 <List Display>
On the <List Setup> page, you can enter a test frequency of up to 201 points, test level, DC Bias,
trigger delay, independent functions corresponding to 4 parameters, 4 independent parameters, and
upper and lower limits corresponding to each list sweep test point. These test points will be
automatically scanned and tested, and the test results will be compared with their corresponding
limit values.
The test points on this display page will be automatically scanned and tested, and the test results are
compared with the limit values. During the list sweep test, the leftmost symbol "*" indicates the
current sweep test point. Display as shown in Figure 3-2-1:
