Tonghui TH2840 Series - Zx Test Conditions Setup

93
7.11.5.5 D Limit Setup
In the transformer Cx limit setting table, touch or move the cursor to D-Std, D-Low and D-High of
Cx to set.
NOTE: The D value test switch is set at the Cx switch.
7.11.6 Zx Test Conditions Setup
On the <Trans Condition> page of the transformer scan, touch or move the cursor to a column of Zx
in the test condition to set the Zx parameters.
