7.13.2 Operation steps for file manage
View existing files.
Click the [+] before the folder icon, or click the folder and right-click to view all the files in this
folder.
Files saved in the root directory can be viewed directly by turning the knob counterclockwise.
Follow the steps below to save control setup parameters to a file.
First set all the control parameters of the desired page.
Press the soft key File to enter the file management page.
When you move the cursor to any file or folder, the menu will display the following:
Save.t40
Copy to E:\
Rename
Delete
New folder
Select Save.t40 to save the settings file.
After pressing the save soft key, the screen will display the soft keyboard.
Enter characters as the file name and press OK to save, press Esc to cancel saving the file.
When saving a file with the same file name, the "File Existing" dialog box will pop up. Select
Overwrite to overwrite the file with the same name; select Rename to re-enter the file name; select
Cancel to cancel the saving of this file.
Press the DISPLAY soft key to enter the transformer scan test page.
Follow the steps below to load control setup parameters from a file.
Press the soft key File to enter the file management page.
Selecting the .t40 file you want to load will display the following menu:
Load
Save.40
Copy to E:
Rename
Delete
New folder
Press the Load soft key and the screen will display the following menu.
Load
Cancel
Pressing Cancel will cancel the current load operation and return to step 1.
Press Load and the currently selected file will be loaded. At the same time, enter the <Trans Scan>
page.
7.13.3 Transformer deviation-deduction
If user has the standard samples of untested transformer, and its data of each test can serve as the
measurement standard, the deviation-deduction function is available.
The operation of deviation function is listed as below：
