142
:FUNC:IMP <para1,para2,para3,para4>
:FUNC:IMP<1|2|3|4> <para>
:FUNC:IMPSW <0|1>,<0|1>,<0|1>,<0|1>
:FUNC:IMPSW?
Parameter:
para1,para2,para3,para4 ----Indicate the optional function parameter name, the value is as follows:
Example:
:FUNC:IMP CP,CS,LP,LS ----Set 4 parameter functions at the same time
:FUNC:IMP1 RP ----Set parameter 1 to RP
:FUNC:IMP2 RS ----Set parameter 1 to RS
:FUNC:IMP3 Z ----Set parameter 1 to Z
:FUNC:IMP4 Y ----Set parameter 1 to Y
:FUNC:IMP1? ----Query the function of parameter 1
:FUNC:IMP2? ---- Query the function of parameter 2
:FUNC:IMP3? ---- Query the function of parameter 3
:FUNC:IMP4? ---- Query the function of parameter 4
:FUNC:IMP? ---- Query the functions of the 4 parameters
:FUNC:IMPSW 1,1,0,0 ---- Set the switches of 4 parameter (on, on, off, off)
:FUNC:IMPSW 1,0,0,0 ---- Set the switches of 4 parameter (on, off, off, off)
:FUNC:IMPSW 1,1,1,1 ---- Set the switches of 4 parameter (on, on, on, on)
:FUNC:IMPSW? ---- Query the switches of 4 parameter (returns such as "1,0,0,0")
9.2.11.2 AC Range
 Description: Set the AC range of the instrument
Command systax:
:FUNC:IMP:RANG?
:FUNC:IMP:RANG <float>
Parameter
name
Parameter
meaning
Parameter
name
Parameter
meaning
CP
Equivalent parallel
capacitance
CS
Equivalent series
capacitance
LP
Equivalent parallel
inductance
LS
Equivalent series
inductance
RP
Equivalent parallel
resistance
RS
Equivalent series
resistance
GP
Conductance
BP
Susceptance
Z
Absolute value of
impedance
Y
Absolute value of
admittance
D
Loss factor
Q
Quality factor
ZTD/DZ
θz° Impedance degree
ZTR/RZ
θz Impedance radian
YTD/DY
θy°Admittance degree
YTR/RY
θy Admittance radian
X
Reactance
RD
DC Resistance
