168
9.2.19.3 Function
 Description: Set the "function" parameters of a single group of specified points
Command systax:
:TRT:FUNC<n>?
:TRT:FUNC<n><para>
Parameter:
n ----Specify the index of the scan point, ranging from 1 to 12
para ---- Indicate the optional function parameter name, the value is as follows:
Example:
:TRT:FUNC1 CP ----Set the parameter function of point 1
:TRT:FUNC5 NS ----Set the parameter function of point 5
:TRT:FUNC12NSNP ----Set the parameter function of point 12
:TRT:FUNC1? ----Return to the parameter function of point 1
9.2.19.4 Frequency
 Description: Set the sweep point frequency
Command systax:
:TRT:FREQ<n>?
:TRT:FREQ<n><fn>
Parameter:
n ---- start from the nth point
fn ---- The floating-point number of sweep point n
Example:
Parameter
name
Parameter
meaning
Parameter
name
Parameter
meaning
CP
Equivalent parallel
capacitance
CS
Equivalent series
capacitance
LP
Equivalent parallel
inductance
LS
Equivalent series
inductance
RP
Equivalent parallel
resistance
RS
Equivalent series
resistance
D
Loss factor
Q
Quality factor
ZX
Absolute value of
impedance
RD
DC Resistance
LK
Leakage inductance
DZ
Impedance degree
NS
Primary turn
NSNP
Primary turn
/secondary turn
NP
Secondary turn
NPNS
Secondary turn
/primary turn
