R/W
0x0051
0x0001
1
0~1
List sweep mode
0
SEQ
1
STEP
R/W
0x0052
R/W
0x0053
0x0001
1
0~200
The sweep point index position in the
current setup
R/W
0x0054
R/W
0x0055
0x0004
4
float
Frequency
R/W
0x0056
0x0005
5
float+char
AC Level +0/1(v/i)
R/W
0x0057
R/W
0x0058
0x0005
5
float+char
AC Level +0/1(v/i)
R/W
0x005A
0x0001~
0x0004
1~4
0~
Function, parameter comparison table is as
follows:
0
CP
6
X
12
Q
1
CS
7
G
13
dZ
2
LP
8
B
14
rZ
3
LS
9
Z
15
dY
4
RP
10
Y
16
rY
5
RS
11
D
17
RD
R/W
0x005C
0x0004
4
float
Step delay
R/W
0x1006
0x0006
6
char+
char+
float
Low limit
Byte meaning:
point index 0~200
abcd index 0~3
float is the value
R/W
0x1007
0x0006
6
High Limit
Byte meaning:
point index 0~200
abcd index 0~3
float is the value
R/W
0x0090
0x0001
1
0~1
LCR Trace ----Scale
0
HOLD
1
AUTO
R/W
0x0092
0x0001
1
0~1
LCR Trace ---- Coordinate
0
Linear
1
Logarithm
R/W
0x0094
0x0001
1
0~1
LCR Trace ----Mode
0
SEQ
1
STEP
R/W
0x0096
0x0001
1
0~4
LCR Trace ----Point
R/W
0x0097
0x0001
1
0~1
LCR Trace ----Max-Min
0
OFF
1
ON
