Tonghui TH2840 Series - Page 198

190
30
/INDEX
Output
When the analog test is finished and
the UNKNOWN terminal can be
connected to another DUT, /INDEX
is effective. But the comparison
signal is effective until /EOM is
effective.
31
/EOM
Output
End Of Measurement：when the test
data and the compared result are
effective, this signal is effective.
32,33
COM2
---
The reference ground for external
power EXTV2.
34,35,36
COM1
---
The reference ground for external
power EXTV1.
Figure 10-2 Example of the distribution area of the comparison function signals /PASS and /FAIL
FAIL
PASS
BIN 1
PASS
BIN 2
BIN 3
BIN 4
BIN 5
BIN 6
BIN 7
BIN 8
BIN 9
BIN 10
FAIL
