Compare output signal: /FAIL1 - /FAIL12, /PASS, /FAIL.
Control output signal: /INDEX (analog measurement end signal)
/EOM (measurement end and comparison data valid signal)
/ALARM (instrument power down signal).
Control input signal: /EXT.TRIG (external trigger signal)
/Keylock.
See Table 10-9 for the signal assignment and brief description of the above pins.
Table 10-9 The signal assignment of
/FAIL1
/ FAIL2
/ FAIL3
/ FAIL4
/ FAIL5
/ FAIL6
/ FAIL7
/ FAIL8
/ FAIL9
/ FAIL10
/ FAIL11
Sorting result
All /FAIL (failure signal) outputs are open
collector outputs.
External trigger:
When the trigger mode is set to single, the
TH2840 is triggered by the falling edge pulse
signal applied to this pin.
External DC voltage 2:
The DC provider pin for the optoelectronic
coupling signal(/EXT_TRIG, /KeyLock,
/ALARM,/INDEX,/EOM)
The internal power +5V: to use the internal
power is not recommended. If you use the
internal power, please ensure that the current
is lower than 0.3A and the signal line is far
from the disturbance source.
As long as the measurement result is in any
one of /FAIL1-/FAIL12, it will be /PASS
If the measurement result is not in any one of
/FAIL1-/FAIL12, it will be /FAIL
Sorting result of the 12th parameter
Factory test signal, please do not connect
When this single is effective, all the front
