4 Vehicle
48 FM-750 Display User Guide
Engage Options
Use this option to view and adjust the settings described below:
Vehicle Setup
Use this option to view and adjust the settings described below:
Setting ... Notes ...
Minimum/Maximum speed Enter the minimum and maximum speeds at which the EZ-Steer
system will disengage:
• Minimum: between 1.0 and 15.9 mph
(1.6 and 25.5 kph).
• Maximum: between 1.0 and 18.0 mph
(1.6 and 28.8 kph).
Maximum Angle The EZ-Steer system will not engage when the vehicle is heading
toward the guidance line at an angle greater than the
Maximum Angle.
Enter an angle between 5 and 45 degrees.
Engage/Disengage Offline Engage offline: The system will not engage when the vehicle is
offline further than the Engage Offline distance. Enter a
distance between 0' 5" and 27' 0" (0.2 and 8.2 m).
Disengage offline: The system will automatically disengage
when the vehicle is offline further than the Disengage Offline
distance. Enter a distance between 0' 6" and 27' 00" (0.2 m and
8.2 m).
Override sensitivity Control how much force is required to disengage the system.
Enter an increment between 1-100%.
EZ-Steer external switch Enable or disable additional safety features.
EZ-Steer operator timeout Enter a time between 1-60 minutes.
Setting ... Notes ...
Vehicle type Enter the type of vehicle on which the EZ-Steer system will be installed.
Wheelbase See Entering vehicle measurements, page 50.
Antenna height See Entering vehicle measurements, page 50.
Antenna to axle
offset
See Entering vehicle measurements, page 50.
Angle per turn Adjust the angle that the wheels turn during one full rotation of the
steering wheel.
Enter an angle between 2-149 degrees.
Freeplay
left/right
Adjust this setting if the vehicle is consistently off to the right or left of the
guidance line.
Enter a measurement of 0-12" (0-30.48 cm).
Motor speed Control the speed of the EZ-Steer drive wheel motor.
Motor direction
is reversed
Select yes or no.
