FM-750 Display User Guide 67
Implement Application Controller 5
Implement Setup
Use this option to adjust the following settings:
• Implement Measurements. If you select this option, the display returns you to
the Implement Measurements screen in the Field-IQ setup wizard. See Step 7,
page 64.
• Section Control Module Setup. If you select this option, the display returns you
to the second part of the Field-IQ setup wizard. See Step 8, page 64.
Section Switching Setup
Use this option to view and adjust the following settings:
Field-IQ System Status
Select this option to view the status for the following:
• Master Switch Module
• Section Switch Module
• Rate Control Module
• Section Control Module
• OEM Switch Interface
• Accessories
Setting ... Notes ...
Coverage switching overlap Control the amount of boom switching overlap allowed before the
section will be switched by the system.
Enter a value between 1 - 99%.
Boundary switching overlap Control the amount of overlap on a boundary before the boom section
is switched off.
Enter a value between 1 - 99%.
On/Off valve latency Tune the section switching to allow for hardware delays.
Enter a time between 0.0 - 10.0 seconds.
Intentional overlap Set a distance to be overlapped when moving to an unsprayed area or
out of a sprayed area.
Enter a distance between 0' 00" - 32' 10" (0.00 - 10.00 m).
