5-10 Expansion Modules
Input/Output Modules
Trio Motion Technology
Specification
Inputs:
16 24volt inputs channels with 2500v isolation
Outputs:
16 24volt output channels with 2500v isolation
Configuration:
16 bi-directional channels
Output Capacity:
Outputs are rated at 250mA/channel. (1 Amp total/
bank of 8 I/O's)
Protection:
Outputs are overcurrent and over temperature pro-
tected
Indicators:
Individual status LED's
Address Setting:
Via DIP switches
Power Supply:
24V dc, Class 2 transformer or power source.
18 ... 29V dc / 1.5W
Mounting:
DIN rail mount
Size:
95mm wide x 45mm deep x 105mm high
Weight:
200g
CAN:
500kHz, Up to 256 expansion I/O channels
EMC:
BSEN50082-2 (1995) Industrial Noise Immunity / BS
EN55022 (1995) Class A Industrial Noise Emissions
