5-23 Expansion Modules
Operator Interfaces
Trio Motion Technology
Keys marked * are not present on Mini-Membrane
<enter> 41 73 13
*Menu Select 4 (Bottom Left) 45 77 50
*Menu Select 3 46 78 51
Menu Select 2 47 79 52
Menu Select 1 (Top Left) 48 80 53
Menu Select 5 (Top Right) 49 81 54
Menu Select 6 50 82 55
*Menu Select 7 51 83 56
*Menu Select 8 (Bottom
Right)
52 84 57
Key
Key # Get #4
Value
Get #3
Value
