106 • Down Force Option User Guide Ver. 7.1.0 2100 Cap Inspector
Down Force Option
What's Inside
This chapter describes the Down Force mechanism that is
used for testing Child Resistant caps.
About the Child Resistant Option
This option enables the Cap Inspector to provide a pre-
settable down force for push and turn caps.
An air supply with the ability to provide a minimum of 60
PSI is required.
Once connected to the air, the down force can be set to the
required force for a given application.
Connecting the Air Supply
The air supply connects to the air filter on the rear of the
tower.
This connection is a
⅛ NPT thread.
Both the air filter and regulator are designed for a maximum
of 100 PSI however the Force Gauge is limited to
either 60 or 30 PSI.
