108 • Down Force Option User Guide Ver. 7.1.0 2100 Cap Inspector
Down Force Mechanism Nomenclature
The names in the callouts below will be used when
describing the setup and adjustment of the Child Resistant
Down Force Mechanism.
Adjusting the Down Force Foot
The Down Force Foot applies the force on the cap by
pressing down on the Drive Shaft Bearing when the Down
Force Switch is actuated.
Foot Position
Shaft Clamp
Down Force
Foot
Drive Shaft
Bearing
Drive Shaft
Clamp Collar
Cap Chuck
Drive Shaft
Foot Support
Shaft
