66 • Creating an ROPP CAP Test User Guide Ver. 7.1.0 2100 Cap Inspector
ROPP Screen Page 2
The ROPP Test Setup Screen (page 2) is
divided into four parts.
Strip Options
Strip Pass / Fail Limits
Close Options
Report Options
Strip Options
Peak Detect: The number of degrees of rotation after a peak
has been measured for the software to accept this peak as the
strip torque value.
Cutoff Torque: The torque at which the test will stop.
Speed: The drive speed prior to slow down to 1 RPM test
speed.
Slow Down At: This is the torque at which the system will
change to the speed for performing the test.
Strip Peak Detect
Observe the minimum and maximum
values.
To input a value, just start typing. The first key
selected will overwrite the first highlighted
value on the screen. When the desired value
has been keyed in press OK to save the new
value.
