User Guide Ver. 7.1.0 2100 Cap Inspector Down Force Option • 109
To adjust the foot put the Down Force switch in the up
position and then place the sample to be tested in the bottle
holding fixture.
Now position the Cap Chuck on the cap by lowering the
drive shaft.
Pivot the Down Force Foot over the top of the Drive Shaft
Bearing and adjust for approximately 1/16 of an inch of
clearance. (i.e. the thickness of a quarter)
Loosening the Foot Position Shaft Clamp and sliding the
Foot Support Shaft up or down and then retightening the
clamp makes this adjustment.
Operating the Child Resistant Mechanism
Once the mechanism has been adjusted, a sample is tested
by pivoting the foot into position and actuating the Down
Force Switch.
At the conclusion of the test cycle, move the switch to the up
position and pivot the foot to the rear.
Repeat this procedure for the next sample.
