86 • Transmitting Test Results User Guide Ver. 7.1.0 2100 Cap Inspector
Transmitting Test Results
What’s Inside
This chapter provides a description of the output port
connector requirements, communication protocol and
procedure for transmitting test results automatically.
Output Port
The Cap Inspector is supplied with an RS-232
Serial communication port for connecting to a
Printer or Personnel computer.
Connector Requirements
The connector is a female, 9 pin Sub-D style
(AMP # 7455201-1).
Amphenol = 17-301-1
