WAGNER TITANUS User Manual

TITANUS MICRO·SENS
®
Technical Description
MS_A_02-a-en-e Data: 01/09 2 – 11
Detector box
Number
in Fig.
2.15
Function Explanation
1
Displays
* Smoke level display 1 to 10
(10 yellow LED’s)
Current smoke level
Operation (green LED) Operation display
Fire alarm (red LED) Smoke level (where main
alarm threshold is set)
Action alarm (red LED) Smoke level (Value as
per main alarm threshold
10 – 80 % adjustable)
Fault (yellow LED) Pipe system fault or
ventilator breakdown or
detector module fault
Infrared interface Commissioning and fault
diagnosis
2
Air sampling pipe connection for ∅ 25 mm pipe system
3
Cable feed, fire alarm cable for switching
on FAS and/or power supply (in / out)
2 x M 25
4
Cable feed fire alarm cable 8 x M 20
5
Cable entries (small) 2 x M 20 for cable with
∅ of 1 to 13 mm
6
Cable entries (large) 1 x M 25 for cable with
∅ of 1 to 18 mm
* optional

WAGNER TITANUS Specifications

General

Power Supply	24 V DC
Operating Temperature	-20°C to +60°C
Alarm Output	Relay contacts
Certification	VdS, EN 54
Humidity Range	10% to 95% (non-condensing)
