WAGNER TITANUS User Manual

Pipe Design TITANUS MICRO·SENS
®
4 – 4 Data: 01/09 MS_A_04-en-e
Branch length In order to ensure a short transport time for the smoke fumes in the sam-
pling pipe and thus enable rapid detection, it is better to plan several
shorter than a few long ones (preferably a U- or double U-pipe system ).
Pipe designs 4 types of pipe designs can be selected, depending on the cabinet ge-
ometry (see Figure 4.2).
I- pipe
An air sampling smoke detection pipe system
without branches.
U- pipe
An air sampling smoke detection pipe system
which branches into 2 air sampling branches after
the connection to the TITANUS MICRO ·SENS
®
.
M-pipe
An air sampling smoke detection pipe system
which branches into 3 air sampling branches after
the connection to the TITANUS MICRO ·SENS
®
.
Double U-pipe
An air sampling smoke detection pipe system
which branches into 4 air sampling branches after
the connection to the TITANUS MICRO ·SENS
®
.
The design for fire location should be the I-pipe configuration.
INSTRUCTION

WAGNER TITANUS Specifications

General

Power Supply	24 V DC
Operating Temperature	-20°C to +60°C
Alarm Output	Relay contacts
Certification	VdS, EN 54
Humidity Range	10% to 95% (non-condensing)
