Yamaha F15A - Fuel Pump Exploded Diagram; Fuel Pump Removal and Installation Chart

FUEL
FUEL PUMP
4-2
E
FUEL PUMP
EXPLODED DIAGRAM
1
2
3
5
4
5
0
9
8
6
7
a
q
REMOVAL AND INSTALLATION CHART
Step
1
2
3
4
5
6
7
8
9
0
q
Q’ty
4
1
1
1
2
1
1
1
1
1
4
Service points
Follow the left ”Step” for disassembly.
NOTE:
To remove the pin, push and turn the
plunger until the slot a is aligned.
Reverse the disassembly steps for installation.
Procedure/Part name
FUEL PUMP DISASSEMBLY
Screw (with washer)
Fuel pump cover
Diaphragm
Fuel pump body
Seat valve
Pin
Plunger
Plunger spring
Diaphragm spring
Diaphragm
Nut
