Yamaha F15A Service Manual

E
DRIVE SHAFT, FORWARD GEAR, SHIFT ROD AND
OIL SEAL HOUSING (F15A/F9.9C)
LOWR
EXPLODED DIAGRAM
6-14
REMOVAL AND INSTALLATION CHART
Step
8
9
10
11
12
13
14
1
2
3
Q’ty
1
1
1
1
1
1
*
2
1
1
Service points
cC
Install the sleeve with its hole facing
forward.
Reverse the removal steps for installation.
Follow the left ”Step” for disassembly.
Reverse the disassembly steps for assembly.
Procedure/Part name
Oil seal housing ass’y
Metal gasket
Shift rod
Sleeve
Needle bearing
Forward gear bearing outer race
Forward gear shim
OIL SEAL HOUSING ASS’Y DISASSEMBLY
Oil seal
Busing
Oil seal housing ass’y
*: as required
