Procedure/Part name

CRANKCASE AND CRANKSHAFT

DISASSEMBLY

Bolt

Crankcase

Dowel pin

Bolt (connecting rod cap)

Connecting rod cap

CRANKCASE AND CRANKSHAFT

POWR

CRANKCASE AND CRANKSHAFT

EXPLODED DIAGRAM

5-35

REMOVAL AND INSTALLATION CHART

Step

Q’ty

Service points

Follow the left ”Step” for disassembly.

M6 x 35 mm

M8 x 55 mm

M7 x 38 mm

NOTE:

Make sure the machining marks a are

aligned (on the side of the connecting

rod).
