Yamaha F15A - Oil Filter, Thermostat and Exhaust Cover; Exploded Diagram; Removal and Installation Chart

E
OIL FILTER, THERMOSTAT AND EXHAUST COVER
POWR
OIL FILTER, THERMOSTAT AND EXHAUST COVER
EXPLODED DIAGRAM
6
5
4
3
7
8
1
2
9
40 Nm (4.0 m•kg, 29 ft•lb)
18 Nm (1.8 m•kg, 13 ft•lb)
12 Nm (1.2 m•kg, 8.7 ft•lb)
10
11
12
1
2
3
4
5
6
7
17
18
16
15
14
13
5-32
REMOVAL AND INSTALLATION CHART
Step
1
2
3
4
5
6
7
8
9
10
Q’ty
1
1
2
1
1
1
5
1
1
3
Service points
Follow the left ”Step” for removal.
M6 x 30 mm
M6 x 30 mm
M6 x 20 mm
Not reusable
Procedure/Part name
OIL FILTER, THERMOSTAT AND
EXHAUST COVER REMOVAL
Oil filter
Oil filter plug
Bolt
Thermostat cover
Gasket
Thermostat
Bolt
Exhaust cover
Gasket
Bolt
