Yamaha F15A - Exploded Diagram (F9.9 C;Ft9.9 D)

FUEL
CARBURETOR
4-8
E
Step
1
2
3
4
5
6
7
8
Q’ty
2
1
1
4
1
1
1
1
Service points
Follow the left ”Step” for disassembly.
Refer to the “INTAKE SYSTEM”.
Procedure/Part name
CARBURETOR DISASSEMBLY
Carburetor
Screw
Carburetor top cover
Gasket
Screw
Float chamber
Rubber gasket
Screw
Float
EXPLODED DIAGRAM (F9.9C/FT9.9D)
4
w
e
1
2
3
r
t
0
q
9
7
8
5
6
REMOVAL AND INSTALLATION CHART
