Yamaha F15A - Starter Motor (Eh;E Models); Starter Motor Disassembly

E
STARTER MOTOR (EH/E MODELS)
ELEC
STARTER MOTOR (EH/E MODELS)
EXPLODED DIAGRAM
2
3
4
1
2
3
4
5
6
7
0
q
r
e
r
i
y
8
9
w
w
e
t
u
u
t
8 Nm (0.8 m•kg, 5.8 ft•lb)
9 Nm (0.9 m•kg, 6.5 ft•lb)
8-23
REMOVAL AND INSTALLATION CHART
Step
1
2
3
4
5
6
7
8
9
0
Q’ty
1
1
1
1
1
2
1
1
1
1
Service points
Follow the left ”Step” for disassembly.
3/16” (3/8” tool)
Procedure/Part name
STARTER MOTOR DISASSEMBLY
Cap
Clip
Pinon gear ass’y stopper
Spring
Pinion gear ass’y
Bolt
Front bracket
Washer
Rear bracket
Armature
