Yamaha F15A - Exploded Diagram; Removal and Installation Chart

Procedure/Part name
Ignition coil lead
Bolt
CDI unit
Spark plug lead
Bolt
Ignition coil
Oil pressure switch
Bolt
Starter motor
E
ELECTRICAL UNIT
POWR
EXPLODED DIAGRAM
10
15
14
10
12
11
13
6
2
1
3
4
5
8
9
7
14
a
a
a
b
5-17
REMOVAL AND INSTALLATION CHART
Step
7
8
9
10
11
12
13
14
15
Q’ty
2
2
1
2
2
1
1
3
1
Service points
M6 x 20 mm
M6 x 20 mm
Reverse the removal steps for installation.
