Yamaha F15A - Exploded Diagram (F9.9 C;Ft9.9 D); Removal and Installation Chart

FUEL
INTAKE SYSTEM
4-5
E
EXPLODED DIAGRAM
REMOVAL AND INSTALLATION CHART
Step
8
9
10
11
12
13
14
15
16
17
Q’ty
1
1
1
1
1
1
4
1
1
2
Service points
M6 x 40 mm
Reverse the removal steps for installation.
Procedure/Part name
Air funnel duct
O-ring
Carburetor
Gasket
Spacer
Gasket
Bolt
Intake manifold
Gasket
Dowel pin
