Yamaha F15A - Page 188

E
MANUAL STARTER (MH MODELS)
POWR
EXPLODED DIAGRAM
1
2
3
4
5
6
7
8
9
0
q
w
e
r
t
y
u
i
o
p
s
a
d
f
g
j
h
k
l
;
zx
i
s
d
i
271
5-3
REMOVAL AND INSTALLATION CHART
Step
i
o
p
a
s
d
f
g
h
j
k
l
;
z
x
Q’ty
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Service points
Reverse the disassembly steps for assembly.
Procedure/Part name
Starter panel ass’y
E-clip
Shaft (choke lever)
Wave washer
Wave washer
Choke lever
Choke knob
Screw
Boot
Nut
Warning lamp ass’y
Spring
Collar
Start-in-gear protection lever
Cover
