Yamaha F15A - Page 222

E
CYLINDER HEAD AND OIL PUMP
POWR
EXPLODED DIAGRAM
8
8
9
12
7
4
5
6
1
3
13
11
10
2
30 Nm (3.0m•kg, 21.7 ft•lb)
12 Nm (1.2m•kg, 8.7ft•lb)
18 Nm (1.8 m•kg, 13 ft•lb)
1
2
3
4
5
6
1
2
3
4
5-20
REMOVAL AND INSTALLATION CHART
Step
8
9
10
11
12
13
Q’ty
2
1
3
1
1
1
Service points
M6 x 35mm
Reverse the removal steps for installation.
Not reusable
Not reusable
Procedure/Part name
Dowel pin
Gasket
Bolt
Oil pump
O-ring
Gasket
