Procedure/Part name
Steering grip
Washer
Spring
Bushing
Bolt
Plate
Bolt
Plate
Throttle shaft
Friction piece
Throttle cable
Engine stop switch
REMOVAL AND INSTALLATION CHART
E
STEERING HANDLE BRACKET (FT9.9DMH, FT9.9DEH)
BRKT
7-8
EXPLODED DIAGRAM
Step
9
0
q
w
e
r
t
y
u
i
o
p
Q’ty
1
1
1
1
2
1
1
1
1
1
2
1
Service points
M6 x 20 mm
M6 x 16 mm
Reverse the disassembly steps for assembly.
